Uniform welding with stable laser output Power density with laser focus.
Fast speed, deep penetration, little deformation.
360° all-round angle micro welding
About Us
Started in the year of 2006, we "M Tech Laser India Pvt. Ltd." established ourselves as a prominent organization of the market in wholesale trading and importing and exporting a wide array of Engraving Machine.
About UsContact Info
- C-609, THE FIRST, NR. ITC NARMADA HOTEL, B/H. KESHAV BAUG PARTY PLOT, VASTRAPUR, AHMEDABAD-380015
- 079-48981589
- mtechlasersolution@gmail.com
Importing and exporting a wide array of Engraving Machine
PRODUCT FEATURES
- The laser welding speed is fast and the efficiency is high, which is 3-6 times higher than that of WIG:
- Good quality and uniform width of weld, beautiful appearance of weld;
- Stable, cost-effective, stable and more cost-saving systems in mass production: Easy to operate and quick to use.
| MODEL | 1000W | 1500W | 2000W |
|---|---|---|---|
| Conduction type | fiber laser | ||
| Laser Frequency (KHZ) | 50-20000 KHZ | ||
| Cooling Method | Water Chiller | ||
| Total power | 7. 5 KW (including water chiller ) |
8. 5 KW (including water chiller ) |
11 KW (including water chiller ) |
| Fiber cable length | 10 m | ||
| Electricity requirements | Single phase 220 v ± 10% 50/60 hz AC |
Single phase 220 v ± 10% 50/60 hz AC |
Single phase 380 v ± 10% 50/60 hz AC |
| Welding mode | Point mode or circular mode | ||
| Filler wire dia | 0.3-1.2 mm | ||
| Welding penetration | 3mm | 4mm | 5mm |
| Welding thickness | 5mm | 6mm | 7mm |
| Working temperature | 10ºC-40ºC | ||
